Core Features
- Large Touchscreen Interface: Equipped with a 10.1-inch color IPS capacitive touch display (1024 × 600 px) for intuitive system management and status monitoring.
- Comprehensive Connectivity: Features built-in communicators including Ethernet, Wi-Fi, and two SIM card slots supporting 2G/4G (LTE) for redundant connection to monitoring stations.
- Scalable Device Capacity: Supports up to 200 wireless addressable Ajax devices and can be organized into 40 distinct fire zones.
- Advanced Wireless Protocols: Utilizes proprietary Jeweller for events/alarms and Wings/TurboWings for photo verification and large data packets, with a range up to 1,800 meters.
- Automation & Integration: Supports up to 64 automation scenarios and provides visual alarm verification through Ajax MotionCam or standard security cameras.
Key Specifications
- Standard Compliance: Certified to EN 54-2, EN 54-4, EN 54-13, EN 54-21, and EN 54-25 standards.
- Power Supply: Operates on 110–240 V~ mains power with terminals for direct connection.
- Backup Battery: Compatible with optional 7.4 V Li-ion batteries (sold separately) providing either 24 or 72 hours of autonomous operation.
- Audio/Visual Alerts: Includes a built-in 60 dB buzzer and 40 individual fire zone LED indicators on the front panel.
- Relay Outputs: Two relay outputs for external signaling (NC for faults, NO for fire alarms).
- Dimensions: Approximately 263 x 223 x 54 mm (or 277 × 267 × 65 mm depending on regional enclosure variations).
